4.16. Anti-tip wheels (optional)

The anti-tip wheels prevent the wheelchair from tipping over backwards.
There must be a gap between the rollers of the anti-tip wheels and the
ground of approx. 30-50 mm (Fig. 32).
Anti-tip wheels are particularly recommended for inexperienced
wheelchair users or amputees.

4.17. Reflectors

As standard your wheelchair is fitted with reflectors on the back and
spokes. These must not be covered.

5. Accessories

5.1.

Lap belt (optional)

You can order a lap belt as an option and this will secure users who do
not have the required stability in the wheelchair.
• Remove the sideguard or swing it away (see Chapter 4.6).
31.
• On both open ends, wrap the belt once round the sideframe tube
• Then fix the belt strap with the buckle.
• You can adjust the belt length using the sliding tabs on the belt.
2
• Use the fastening clip to open and close the belt.
5.2.

Therapy table (optional)

1
The table is simply pushed into the armrest from the front. To
remove the therapy table, simply pull it back out.
5.3.

Togo (optional)

32.
An electrical Togo pushing & braking aid can be fitted to your
wheelchair.
If required, see the Togo pushing & braking aid user manual for all
relevant information on assembling and use.
72 72
For safety reasons, always use the anti-tip wheels
as a pair!
Leichtgewichtrollstuhl |
5.4.

Crutch holder (optional)

Put the crutch in the crutch holder and then fix it to the backrest using
the retaining strap.
Never step on the crutch holder and never use it as a tipping aid.
5.5.

Spokeguard (optional)

The spokeguard is fixed to the spokes using the cable ties.
5.6.

Headrest

The headrest is screwed onto the push handles. After loosening the
clamping lever or star screw, you can adjust the position of the headrest.
Then tighten the screws firmly.
5.7.

One-hand operation (optional)

With one-hand operation you have both handrims on one wheel, so
that you can operate both drive wheels with one hand.
The option can be fitted either left or right.
5.8.

One-hand brake (optional)

With the one-hand brake you have a parking brake where you can
brake both drive wheels by pressing only one brake lever.
The option can be mounted on the left or right.
5.9.

Handrim cover (optional)

Put the handrim cover over the handrims in order to achieve better grip
on the handrim, for example if your hand strength is limited.
With better grip, there is a risk of sharp braking.
Attention: risk of falling!
