RL-120 / SL
| Rollator
4.
Assembly/adjustments
4.1. Attach wheels and
adjust seat height
•
The movable steered wheels are inserted at the front. To do this,
press in the pushbuttons and push the tube into the frame. The
pushbuttons click into place in the holes located on the sides.
4
•
The fixed wheels are attached at the back in the same way as the
front wheels. (Fig 4)
•
You can adjust the height of the rollator and the seat height via the
holes
•
The holes, which run from front to back, are used for the additional
securing sleeves. These are placed through both tubes and closed
by pressing on the rear of the sleeve ring. (Fig. 5).
5
4.2.
Unfolding
•
Position the rollator in the travel direction.
•
Release the locking brakes (see sec. 4.7).
•
Tip the B+B rollator towards yourself until the load is taken off the
steered wheels and press the handles downwards at the same time
with a gentle jolt.
•
To lock the folding mechanism, now fold the seat plate tight to
6
your seat (Fig. 6). You can hear this click into place.
•
This means the rollator is locked into position.
30
4.3.
Folding
•
Position the rollator in the travel direction.
•
Activate the locking brakes.
•
Hold the rollator firmly with one hand on the handle.
•
Now grasp the slot in the seat plate provided for this purpose and
pull the locking lever on the left upwards with the plate. You can
hear it click out of place (Fig. 7). Ensure that neither body parts nor
articles of clothing get jammed during the folding
4.4.
Attach basket and tray
•
The rollator is unfolded. Activate the locking brakes.
•
Position yourself against the travel direction in front of the rollator.
•
The basket can be hung on the hooks on the left and right of the
rollator (Fig. 8) and sits on the frame.
•
To remove the basket, simply grasp the carrying handle and pull it
up and off.
•
Place the tray onto the seat from above in such a way that the four
plastic pins of the tray fit into the holes of the seat (Fig. 9).
4.5. Fitting the backrest
•
The upholstered backrest is inserted into the frame on the
handlebars. To do this, hold the lateral pushbuttons pressed in
(Fig. 10). When you hear the pins click into place, the backrest has
been correctly fitted.
Bischoff & Bischoff GmbH | 21.10.2019 - Revision: 1
RL-120 / SL
Rollator |
7
process.
8
9
10
31
