RL-120 / SL
| Rollator
You can determine the change of direction and speed by pushing
the rollator. Always use the brakes to slow down your movement. The
rollator could otherwise turn with the unbraked wheel and the braked
wheel, and could fall over.
Go around obstacles whenever possible. Try to use ramps or take lifts. If
this is not possible, the rollator must be carried over the obstacle. Find
a second person to help you do this, if possible.
The seat
The rollator is also designed to be used as a seat by the user for short
breaks. It is therefore equipped with a seating area. You must absolutely
activate the locking brakes before sitting down. The rollator could roll
away and you could fall.

Lifting points

You can lift the rollator on the grips or frame sections, in order to carry
it over obstacles or steps.

6. Technical data

Dimensions and weights
Type:
Colour:
Model:
Height (push handle height):
Length:
Folded:
Width:
Width between handles:
Width of handles:
Angle of push handles max.:
34
Rollator
Silver
4021* / 4024**
max. 925 mm*
max. 1055 mm**
670 mm*
710 mm**
300 mm
620 mm*
630 mm**
455 mm
30 mm (support surface 50 mm)
0°
Seat height: 510 mm*
590, 615, 640 mm**
Seat width: 355 mm
Effective seat width: 440 mm
Turning radius: 1240 mm
Weight: 7,4 kg including basket and tray*
7,7 kg including basket and tray**
Max. load: 120 kg
Max. load of bag: 5 kg
Tyres
Rear wheels: 200 x 35 mm
Steered wheels: 200 x 35 mm
Material
Frame: steel, corrosion-resistant coating
Handles: TPR
Seat: ABS
Flammability: flame-retardant
Operating conditions
Temperature: 0 to 35°C
Air humidity: 20 to 80%

Storage conditions

Temperature: -20 to + 60°C
Air humidity: 45 to 80%
• Including basket, tray and cane holder
• Anatomically shaped handles
• Combined operating and locking brake
• Stable steel design, corrosion-resistant coating
• Non-rotating handholds
Standard equipment for:*RL-120 / **RL-120 SL
Bischoff & Bischoff GmbH | 21.10.2019 - Revision: 1
RL-120 / SL
Rollator |
35
