Fig. 2: Size 6S, 6D, 7S, 7D, 8S, 8D
1 Rotary actuator
2 Foot mounting
3 Flange mounting
4 Sensor mounting plate
5 Sensor holder with sensor
5.2

Rotary actuator, series RAK, size 6 to 8

5
4
1
2
5.3

Accessories

All accessories can either be ordered together with the rotary
actuator, or separately. Accessories are always supplied unfitted.
6
7
6 Swivel arm with magnet
7 Hydraulic shock absorber
8 Swivel arm without magnet
9 Swivel arm with magnet
8
9
