Technical Data
Self-levelling range
Accuracy Hz
Accuracy V
Working range with receiver FR 77-MM TRACKING M
Laser class
Slope horizontal mode
X axis
Y axis
Both axes X/Y
Slope vertical mode
X axis
Y(Z) axis
Working range of tracking function
Rotating speed
Operating time
Power supply
Working range of RF remote control
Channels
Temperature range
Dust / water protection
Weight (instrument only)
FUNCTIONS
· Dual Grade Laser
· Horizontal and vertical
· Digital slope setting
· Combine manual and automatic slope
setting in two axes
· TILT function
· VWS function
· Tracking function (horizontal and vertikal)
± 8°
± 0,5 mm / 10 m
± 1 mm / 10 m
Ø 800 m
2
± 10,000 %
± 10,000 %
∑ ± 14 %
± 10,000 %
horizontally self-levelled
140 m*
300 / 600 / 1100 rpm
40 h
intelligent / Li-Ion
(Alkaline alternatively)
100 m
8
-10 °C – +50 °C
IP 66
3,85 kg
* depending on environmental conditions
· Monitored tracking function (horizon-
tal and vertical
· Shield function
· 90° plumb beam up
· Illuminated display
· 2-way RF remote control
· Manual function
· Li-Ion or alkaline batteries
· Dust/water protection IP 66
