ISTRUZIONI MONTAGGIO ACCESSORI - ACCESSORIES ASSEMBLY INSTRUCTIONS
SALINA glass assembling
A Canopy lamp
B Side glass
C Frontal glass
D Mezzanine glass-shelf
E Mezzanine glass-shelf side support
F Mezzanine glass-shelf central support (200 – 250 – 300)
G Side wall
H Curved frontal panel
I Lower panel
L Self-threading screw + tube + screw covering
bosses
M Threaded screws + washer + screw covering
bosses
N Steel screw + tube + black rubber cap
Boss cap
1.
Self-threading screw
2.
FRONT PANEL ASSEMBLING
1.
Insert lower side of curved frontal panel
2.
Slightly press and insert upper part of curved frontal panel
GLASS ASSEMBLING INSTRUCTIONS
1. Position side glass ( key B) and secure with 2 t a sinless steel self-threading screws complete with black top and rubber cap ( do
not insert bosses) Proceed with second side glass assembling ( key B). See B-B section.
2. Fix canopy lighting ( Key A) onto upper holesf o side glass ( Key B) by mean of 2 self-drilling screws with black top and bosses.
Insert 2 boss-covers. Proceed the same way on the opposite side( see A-A section)
3. Position mezzanine glass shelf( Key D) onto ala r d e y mounted relative supports (Key E) ( If not mounted, follow scheme in C-C
section)
4. Insert frontal glass (key C)in relative guides ( e e "X" detail)
For 200-250 and 300 cm models fix central mezzanine glass-shelf support in middle part of counter and secure by mean of 2 screws
on relative holes on tank( see "x" detail)
REAR SLIDING-DOORS ASSEMBLING
Secure with silicone aluminium profile „A" on inner side of steel profile „B" ( See section picture)
1.
Secure with silicone aluminium profile „C" to canopy lamp.
2.
Insert lexiglas rear sliding doors in corresponding aluminium guides.
3.
Istruzioni montaggio vetri
2
Mounting instruction for glasses
Appendici | Manuale d'uso e manutenzione | IT - EN - F - DE
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
Tube
Boss
Side glass
Top lighting profile
View
Threading screw
Mezzanine glass-shelf
Mezzanine glass-shelf support
Screw nut
Side wall
Rubber cup
Self-threading screw
Mezzanine glass-shelf central support
Self-threading screw UNI 6954 4.8x32
Guide
Frontalglas
