Configure Power Supply
mode
Using the NEXT (>) button, this value can be changed between 10.5V and 14.5V (or between
21.0V and 29.0V on a 24V charger) with a step size of 1V. Once you have selected the
desired value, press the SET button to jump to the maximum output current setting:
Set output voltage
Using the NEXT (>) button, this value can be changed between 60A and 5A (depending on
charger model) with a variable step size. Once you have selected the desired value, press the
SET button to jump to the END screen:
Set maximum current
In order to actually activate the Power Supply mode, the MENU button must be pressed for
3 seconds while operating in any of the four above displayed Power Supply setup screens.
Please note that it can take up to 10 seconds before the charger is actually
producing the desired voltage at the output terminals.
In Power Supply mode all three outputs (B1, B2 and B3) are active. The maximum
output current will be shared between these three outputs, based on the
consumption of the connected loads.
SET Set output voltage
SET Set maximum current
End of Power Supply setup
SET
