Set end of charge current
This setup parameter represents the charge program mode and is indicated by the letter 'M'
in front of the mode value. The charge program mode can be set to values 3 or 2. When the
value is set to 3, the charge program contains a Float stage (3-stage charge program). When
the value is set to 2, the charge program only contains 2 stages (bulk and absorption). In this
case, the charger stops charging after the absorption stage has ended. Once you have
selected the desired value, press the SET button to jump to the next setup parameter as
indicated below. This next setup parameter will only appear when the charge program mode
has been set to 3. Otherwise the next step will be skipped.
Set charge program mode
This setup parameter represents the Float voltage and is indicated by the upper two
segments inside the battery icon. This value can be changed between 13.0V and 14.0V with a
0.1V step size. Once you have selected the desired value, press the SET button to jump to
the next setup parameter as indicated below. This next setup parameter will not appear
when the earlier selected battery type is set to Lithium.
Set Float voltage
This setup parameter represents the average battery temperature and is indicated by the
letter 'T'. This parameter can be set to T.NO (normal), T.LO (low) and T.HI (high) and decides
the level of charge voltage compensation for GEL, AGM and Flooded battery types. For more
information, please check chapter 3.3. When a battery temperature sensor (BTS) is
connected to the charger, this setup parameter will be disabled automatically and the actual
SET Set charge program mode
SET Set Float voltage
SET Set battery temperature
20
