OPTIONAL EVOLUTION ACCESSORIES

CROWN MOULDING CUTTING

This machine is capable of cutting the
mitre angles required for Crown Mouldings.
DUST BAG (Supplied with R255SMS+)
To configure the machine to cut Crown A Dust Bag can be fitted to the extraction port
Moulding:
at the rear of the machine. The Dust Bag is for
• Deploy the 33.9˚ Bevel Pin by pushing it fully
use when cutting wooden materials only.
inwards. (Fig. 59)
• Tilt the cutting head to the 33.9˚ position
• Slide the Dust Bag over the dust extraction
and lock it in place by tightening the bevel
lock handle.
• Turn the rotary table and set it to 31.6˚ mitre
angle as indicated by the protractor scale.
Note: For operational efficiency empty
Ensure that the Crown Moulding is correctly
the Dust Bag when it becomes 2/3 full.
positioned on the rotary table and secure it with
Dispose of the contents of the Dust Bag in an
appropriate clamps before making the cut.
environmentally responsible way. It may be
necessary to wear a dust mask when emptying
When cutting operations are completed,
the Dust Bag.
return the cutting head to the vertical position
and return the 33.9˚ Bevel Pin to its outer
Note: A workshop vacuum extraction machine
(disengaged) position.
can be attached to the dust extraction
port if required. Follow the manufacturers
CUTTING BOWED MATERIAL (Fig. 63)
instructions if such a machine is fitted.
WARNING: Before cutting any work-piece, check
to see if it is bowed. If it is bowed the work-piece
WARNING: Do not use the Dust Bag when
must be positioned and cut as shown.
cutting metallic materials including wood
Do not position the work-piece incorrectly or cut
with nails.
the work-piece without the support of the Fence.
EXTRACTION PORT ADAPTOR

CLEARING JAMMED MATERIAL

TUBE (Supplied with R255SMS+)
• Turn mitre saw "OFF" by releasing the
Use the Adaptor Tube to connect the
trigger switch.
extraction port of the machine to suitable
• Allow the blade to come to a complete halt.
commercial workshop vacuum extraction
• Unplug the mitre saw from the mains supply.
equipment (not supplied) which have ø30mm
• Carefully remove any jammed material from
internal bore hoses or inlet ports.
the machine.
• Check the condition and operation of the
safety guard.
• Check for any other damage to any part of
the machine e.g. the blade.
• Have any damaged parts replaced by
a competent technician and a safety
inspection carried out before using the
machine again.
The free end of a long work-piece should be
supported at the same height as the machines
rotary table. The operator should consider
using a remote work-piece support stand,
adjustable workmate or saw horse etc.
32
www.evolutionpowertools.com
port, ensuring that the spring clip grips the
port holding the Dust Bag securely in place.
(Fig. 64)
www.evolutionpowertools.com

MAINTENANCE

Note: Any maintenance must be carried
out with the machine switched off and
disconnected from the mains/battery
power supply.
Check that all safety features and guards
operating correctly on a regular basis. Only use
this machine if all guards/safety features are
fully operational.
All motor bearings in this machine are
lubricated for life. No further lubrication
is required.
Use a clean, slightly damp cloth to clean
the plastic parts of the machine. Do not use
solvents or similar products which could
damage the plastic parts.
WARNING: Do not attempt to clean
by inserting pointed objects through
openings in the machines casings etc. The
machines air vents should be cleaned using
compressed dry air.
Excessive sparking may indicate the presence
of dirt in the motor or worn out carbon
brushes. If this is suspected have the machine
serviced and the brushes replaced by a
qualified technician.

ENVIRONMENTAL PROTECTION

(6.4)
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
