MACHINE OVERVIEW

1
2
3
4
5
6
7
8
9
10
22 23 24
1. CUTTING HANDLE 14. BLADE
2. BLADE GUARD LOCKING TRIGGER 15. LOWER BLADE GUARD
3. DUST BAG* 16. TABLE TOP
4. SLIDE LOCKING SCREW 17. ROTARY TABLE
5. DEPTH GAUGE 18. TABLE INSERT
6. 2 PC HOLD DOWN CLAMP 19. MITRE HANDLE LOCKING KNOB
7. SLIDING FENCE 20. POSITIVE STOP LOCKING LEVER
8. MACHINE TABLE EXTENSIONS 21. MITRE ANGLE SCALE
9. MOUNTING HOLE (X4) 22. SLIDE RAIL PROTECTOR*
10. FRONT CLAMP HOLES 23. DUSTPORT ADAPTER*
11. BLADE ROTATION INDICATION ARROW 24. 3 PC HOLD DOWN CLAMP*
25. FRONT CLAMP*
12. UPPER BLADE GUARD
13. CUTTING HEAD
*Supplied as original equipment on the R255SMS+.
14
www.evolutionpowertools.com
Pictured: R255SMS (See * for R255SMS+ Parts)
11
12
13
14
15
16
17
18
19
20
21
25
www.evolutionpowertools.com
27
32
33
35 36 37
26. ON / OFF TRIGGER SWITCH 37. CABLE GRIP COMPONENT
27. LASER GUIDE ON / OFF SWITCH
38. ANTI-VIBRATION SPRING
28. DUST EXTRACTION PORT
29. CABLE
30. CUTTING HEAD LOCKING PIN
31. REAR SLIDING CARRIAGE
32. CABLE GUIDE CLAMP
33. 33.9˚ BEVEL PIN
34. BEVEL LOCK HANDLE
35. M4 SELF TAPPING CAP SCREW x1
36. M4 SOCKET HEAD SCREW x4
15
Pictured: R255SMS
26
28
29
30
31
32
34
38
(FITTED TO THE CABLE GUIDE CLAMP)
(FITTED TO ITEM '4' - THE SLIDE LOCKING
SCREW)
