Technical Data - Vetus CWS Instructions D'installation

Check the seal between lid and housing after
cleaning and re­assembling the strainer. An
improperly sealed lid will result in air sucked
in by the sea water pump of the engine which
again will result in overheating of the engine.
To prevent damage of the water strainer, dur­
ing frost in the winter time, either the water
must be drained or the installation must be
filled with anti­freeze.
Remove the hoses to drain the strainer; the
housing is not equipped with a drain plug.
Take care that during filling with anti-freeze
no anti-freeze is spilled into the waterway.
Anti-freeze is poisonous.
Model
CWS 1
1
CWS 1 /
4
CWS 1 1 /
2
Cooling water strainer model CWS

Technical data

Material
­ housing
­ strainer element
­ lid
Weight
Max. ambient temp. : 75 °C (167°F)
Max. water temp.
Max. pressure
Hose connection
G 1
G 1 1 /
4
G 1 1 /
2
ENGLISH
: Polypropylene GF
: HD Polyethylene
: Styrol/Acrylnitrile SAN
: 6.2 kg (13,7 lb)
: 55 °C (131°F)
: 7.5 bar
(750 kPa, 109 psi)
Recommended capacity
in normal use
l/min Imp.Gal/min US Gal/min
91 20
143 31
200 44
030507.01
24
38
53
5
