Vessel: operational characteristics
Nominal Permissible
capacity positive
operating
pressure
[litres] [bar]
150 - 3500 3
5000 - 10000 3
Pump module: dimensions and weights
Type Height
[mm]
MP M-2-50 (MM)
MP 0...2-3-50 (M0...2)
MP 10-1-50 (M10)
MP 20-2-50 (M20)
MP 60-1-50 (M60) 842
MP 80-1-50 (M80) 878
MP 100-1-50 (M100) 1030
MP 130-1-50 (M130) 1190
DP M-2-50 (DM)
DP 0...2-3-50 (D0...2)
DP 10-1-50 (D10)
DP 20-2-50 (D20)
DP 60-1-50 (D60) 842
DP 80-1-50 (D80) 878
DP 100-1-50 (D100) 1030
DP 130-1-50 (D130) 1190
Example: MP 0...2-3-50
Installation and operating instructions Wilo-Sinum
Positive Temperature
test pressure min.
(design)
[bar] [°C]
4,72 0
4,72 0
Length Width
[mm] [mm]
660 420 330
840 530 540
840 530 540
840 530 540
610 535
610 595
610 595
610 595
660 385 340
840 900 670
840 900 670
840 900 670
850 580
910 580
910 580
910 580
Temperature Permissible
max. permanent
(design) temperature
at the diaphragm
min.
[°C] [°C]
120 0
120 0
Connection Connection Connection
system top-up
Connection
array
(vessel)
[G, inch] [inch] [Rp, inch]
1 Rp ¾ ½
1¼ G 1¼ ½
1¼ G 1¼ ½
1¼ G 1¼ ½
1½ G 1½ ½
1½ G 1½ ½
1½ G 1½ ½
1½ G 1½ ½
1 Rp ¾ ½
1½ G 1½ ½
1½ G 1½ ½
1½ G 1½ ½
1½ G 1½ ½
1½ G 1½ ½
1½ G 1½ ½
1½ G 1½ ½
English
Permissible
permanent
temperature
at the diaphragm
max.
[°C]
70
70
Dead weight
(as delivered
condition
without
packaging)
[kg]
12
37
37
37
54
63
67
75
14
63
66
69
108
124
134
153
Fig. FM.043.V02.15
