GENERATORS
Table of characteristics for single voltage
Hz
IS 21.5 50
IS 23.5 60
Table of characteristics for double voltage
Hz
IS 21.5 50
IS 23.5 60
6.4.

Generator - Mains switching

A switch should be placed on the line to switch the user
appliances from the generator to an external power line.
The switch should be dimensioned according to the size
of the loads: a general diagram is shown in fig.15.

7 HANDLING

For handling and lifting the generator use only the
special lifting hooks fitted on the engine. To prevent
balancing problems, use the hooks simultaneously and
never individually.
Hooking the generator at points
different from those indicated may cause damage to
the generator or present a risk to the operators.
V kW A
115 156.5
18
230 78.2
120 175
21
240 87.5
V kW A
115
18 78.2
230
120
21 87.5
240
GB

8 WIRING DIAGRAM REFERENCES

See Fig.16
1 - Magnetothermal switch
2 - Hour counter
3 - Alternator
4 - Rotor
5 - Stator
6 - Voltage regulator
7 - Power terminal board
8 - /
9 - Thermal switch
10 - START / STOP- button
11 - Engine protection module
12 - Terminal board
13 - Connector for remote control panel connection
14 - Fuel level gauge
15 - Oil pressure gauge
16 - Water temperature gauge
17 - High water temperature sensor
18 - High coolant temperature sensor
19 - Oil pressure switch
20 - Battery charger alternator
21 - Stop electromagnet
22 - Starter motor
23 - Battery connection terminals
24 - Panel connection cable
25 - START / STOP- button
26 - Oil pressure gauge instrument
27 - Coolant temperature gauge instrument
28 - Remote control panel kit with instruments
29 - Remote control panel kit
- 18 -
IS 21.5-23.5
