EUROM CWC9000B Manuel D'utilisation page 17

The Air Cooler has the following functions:
Cooling: cools air by evaporating water, even in a damp or windy space.
Air humidification: the evaporated water humidifies air in the room.
Air cleansing: a functioning unit filters fine particulates, fibres etc and also air pollution and
nicotine from the air and thus helps create a clean and healthy environment.
Ionisation: removing ions from the air makes it extra clean and also increases the oxygen
level; this is beneficial for heart and lung functions, resistance to disease, sleep and so on.
Swivelling: the cooled air can be emitted horizontally over a 120° angle. The vertical direction
can be set manually.
Fan: the fan can be set at a range of ventilation types and speeds.
Remote control: the unit can be operated using the remote control from 6 metres away and
within an angle of 120°.
The device is energy efficient and only uses water for cooling purposes: it uses no chemical
agents and is therefore environmentally-friendly. The unit is easy to clean.
Wheel assembly
You do not need to assemble the wheels: the unit is most stable when placed on the
base plate, without wheels. If you would nevertheless like to attach the wheels,
please do so as follows:

Place the unit with its back on a soft, level surface.

Remove the four rubber stoppers from the holes in the base plate

Push 2 swivel wheels into the front holes (1) using the pins and make sure they are
secure.

Push 2 swivel wheels into the back holes (2) using the pins and make sure they are
secure.

Put the unit in an upright position, on the wheels.
Installation and Preparation

Place the unit straight, on a sturdy, flat and horizontal surface. Ensure there is sufficient
space at the front (air outlet) and sides (air inlet). The back of the unit may rest against a
wall, if necessary.

Check whether the socket that you wish to use provides the required voltage, as detailed
on the specification plate.

Pull the water reservoir roughly 10 cm backwards and fill with clean water; do not exceed
the 'MAX' level!

If you have not used the unit for some time, refresh any remaining water.

If you wish to use the humidification function, ensure there is sufficient water in the
reservoir.
Optionally mounting the swivel wheels
affects the stability of the air cooler!
17
