3-WIRE CONNECTION (GROUNDED NEUTRAL)
WARNING
ELECTRICAL SHOCK HAZARD
Grounding through the neutral conductor is prohibited for
new branch-circuit installations (1996 NEC); mobile homes;
and recreational vehicles, or in an area where local codes pro-
hibit grounding through the neutral conductor. For installations
where grounding through the neutral conductor is prohibited,
see the Ungrounded Neutral graphic.
Use grounding terminal or lead to ground unit.
Connect neutral terminal or lead to branch circuit neutral in
usual manner.
Failure to do so could result in death, fire or electric shock.
3-WIRE CABLE FROM HOME POWER SUPPLY
IMPORTANT: Use the 3-wire cable from home power supply where
local codes permit a 3-wire connection.
1 Disconnect power.
2 Connect the two black wires B together using a CUL listed wire
connector.
3 Connect the two neutral (white) wires C and the ground (green or
bare) wire d (of the oven cable) using a CUL listed wire connector.
4 Connect the two red wires G together using a CUL listed wire
connector.
5 Install junction box cover.
4-WIRE CONNECTION (UNGROUNDED NEUTRAL)
4-WIRE CABLE FROM HOME POWER SUPPLY
IMPORTANT: Use the 4-wire cable from home power supply in
the U.S. where local codes do not allow grounding through neutral.
1 Disconnect power.
2 Connect the 2 black wires B together using a CUL listed wire
connector.
3 Connect the 2 red wires C together using a CUL listed wire
connector.
4 Untwist white wire from green (or bare) ground wire coming
from the oven.
5 Connect the 2 neutral (white) wires H together using a CUL listed
wire connector.
6 Connect the ground (green or bare) wire FA from the oven cable
to the ground (green or bare) wire (in the junction box) using a
CUL listed wire connector.
7 Install junction box cover.
