Sharp SUPERSTEAM+ SSC2489DS Guide D'installation

SPECIAL WARNING
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE THIS INSTALLATION MANUAL FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CLEARANCES AND DIMENSIONS
For SAFETY CONSIDERATIONS do not install oven in any combustible cabinetry which is not in accord with the stated
clearances and dimensions on page 3, Figure 2 or page 4, Figure 3.
UNPACKING YOUR OVEN
Remove all packing materials from inside the oven.
•
Check the oven for any damage, such as misaligned or bent oven,
•
damaged oven seals and sealing surfaces or dents inside the
cavity or on the front side of the oven. If there is any damage,
do not operate the oven. Contact your dealer or a SHARP
AUTHORIZED SERVICER.
IMPORTANT NOTES TO THE INSTALLER
Read all of the Installation Manual before installing the oven.
•
Remove all packing material before connecting the electrical
•
supply.
Observe all governing codes and ordinances.
•
Be sure to leave these instructions with the consumer.
•
IMPORTANT NOTES TO THE CONSUMER
Keep this manual with your Operation Manual for future reference.
As when using any oven generating heat, there are certain safety
•
precautions you should follow. These are listed in the Operation
Manual. Read all and follow carefully.
This oven should only be installed and grounded properly by
•
a qualified installer or service technician.
IMPORTANT SAFETY INSTRUCTIONS
If the information in this manual is not followed
exactly, a fire or electric shock may result that could cause
property damage, personal injury or death.
This oven must be electrically grounded in accordance with
•
local codes.
Do not install this oven if the surrounding wall coverings and
•
the cabinets cannot withstand the heat generated by the oven.
SSC2489DS SUPERSTEAM +
INSTALLATION MANUAL
OVEN
™
Never leave children alone or unattended in
the area where an oven is in use.
Do not use the oven as a storage space. This creates a
•
potentially hazardous situation.
INSTALLATION HARDWARE
NAME
Wood Screws
CHOOSING A LOCATION FOR YOUR OVEN
You will use your oven frequently, so plan its location for ease
of use. Your oven can be built into a cabinet or wall by itself, or
above any electric wall oven or above other Microwave Drawer
models that specify the combination of this oven. The oven may
be mounted below a 36" countertop, including a cooktop or island.
It cannot be built in above any gas wall oven.
Min.
2"
(5.1 cm)
Min.
36"
(91.5 cm)
1
QTY PART CODE
4 XTSS740P20000
SuperSteam+ Oven
Cutout
Electric Wall Oven /
Warming Drawer /
Microwave Drawer
Cutout
E
