SSC2489GS SMART COMBI STEAM OVEN
SPECIAL WARNING
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE THIS INSTALLATION MANUAL FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CLEARANCES AND DIMENSIONS
For SAFETY CONSIDERATIONS do not install oven in any combustible cabinetry which is not in accord with the stated
clearances and dimensions on page 3, Figure 2 or page 4, Figure 3.
UNPACKING YOUR OVEN
Remove all packing materials from inside the oven before
•
installation and operation.
Check the oven for any damage, such as misaligned or bent door,
•
damaged oven seals and sealing surfaces or dents inside the
cavity or on the front side of the oven. If there is any damage,
do not operate the oven. Contact your dealer or a SHARP
AUTHORIZED SERVICER.
IMPORTANT NOTES TO THE INSTALLER
Read the entire Installation Manual before installing the oven.
•
Remove all packing material before connecting the electrical
•
supply.
Observe all governing codes and ordinances.
•
Leave these instructions with the consumer.
•
Installation of this oven requires two people.
•
IMPORTANT NOTES TO THE CONSUMER
Keep this manual with your Operation Manual for future reference.
As when using any oven generating heat, there are certain safety
•
precautions you should follow. These are listed in the Operation
Manual. Read all and follow carefully.
This oven should only be installed and grounded properly by
•
a qualified installer or service technician.
IMPORTANT SAFETY INSTRUCTIONS
If the information in this manual is not followed
exactly, a fire or electric shock may result and cause property
damage, personal injury or death.
This oven must be electrically grounded in accordance with
•
local codes.
INSTALLATION MANUAL
Do not install this oven where the surrounding wall coverings
•
and the cabinets cannot withstand the heat generated by the
oven.
Do not use the oven as a storage space.
INSTALLATION HARDWARE
NAME
Wood Screws
CHOOSING A LOCATION FOR YOUR OVEN
You will use your oven frequently, so plan its location for ease
of use. Your oven can be built into a cabinet or wall by itself or
above any electric wall oven or Microwave Drawer model that
specifies the combination of this oven. The oven may be mounted
below a 36" countertop, including a cooktop or island. It cannot
be built in above any gas wall oven.
Min.
2"
(5.1 cm)
Min.
36"
(91.5 cm)
1
QTY PART CODE
4 LX-CZB073MRE0
Smart Combi Steam
Oven Cutout
Electric Wall Oven/
Warming Drawer/
Microwave Drawer
Cutout
E
