OPENING DIMENSIONS

A Cutout height 43
B Cutout width 28
C Cutout minimum depth 24"
D Top of cutout to top of Control Panel 1
E Bottom of cutout to floor 17
NOTE:
Cabinet wall thickness is
AC cord length is 48"
* Junction box may be located in adjacent cabinet.
H
A
E
1 / "
4
11 / "
16
3 / "
4
F
D
I
C
F Standard cabinet depth 24"
G Standard countertop height 36"
H Cabinet height 80"
3 / " I Junction box location 4" *
4
7 / "
8
4
G
