GEMÜ BB02 Notice D'utilisation page 20

9 Dimensions
9.2.5 Embout ASME (code raccordement 59)
øk
DN øc ød
15 9,4 12,7
20 15,7 19,0
25 22,1 25,4
40 34,8 38,1
50 47,5 50,8
65 60,2 63,5
80 72,9 76,2
100 97,4 101,6
Dimensions en mm
GEMÜ BB02
M1
h øk s
8,5 46,0 1,65
10,5 47,0 1,65
12,0 56,0 1,65
14,5 79,0 1,65
14,5 98,5 1,65
14,5 126,0 1,65
17,5 146,0 1,65
17,5 180,0 2,15
LB
L
L LB
140,0 25,0
146,0 28,0
159,0 32,0
191,0 48,0
216,0 62,0
248,0 80,0
267,0 90,0
318,0 118,0
20 / 31
LS
LS H1 M1
57,5 40,5 M8
59,0 43,5 M8
63,5 50,5 M8
71,5 67,5 M10
77,0 75,5 M12
84,0 88,0 M12
88,5 105,0 M14
100,0 120,0 M14
www.gemu-group.com
T
5,0
5,0
7,0
8,0
8,0
8,0
10,0
10,0
