9 Dimensions
9.2.3 Embout EN 10357 série A (code raccordement 17)
øk
DN øc ød
10 10,0 13,0
15 15,0 19,0
20 20,0 23,0
25 25,0 29,0
32 32,0 35,0
40 38,0 41,0
50 50,0 53,0
65 65,0 70,0
80 80,0 85,0
100 100,0 104,0
Dimensions en mm
GEMÜ BB02
M1
h øk s
9,0 46,0 1,5
9,0 46,0 1,5
10,5 51,0 1,5
12,5 61,0 1,5
12,5 73,0 1,5
16,0 83,0 1,5
16,0 101,0 1,5
15,0 130,0 2,0
18,0 155,0 2,0
18,0 187,0 2,0
LB
L
L LB LS
120,0 24,0 48,0
140,2 24,0 58,0
140,0 29,0 55,5
152,2 35,0 58,5
165,1 44,0 60,5
190,4 53,0 68,5
203,0 65,0 69,0
254,0 81,0 86,5
280,2 96,0 92,0
317,0 124,0 96,5
18 / 31
LS
H1 M1 SW
40,5 M8 18,0
40,5 M8 18,0
45,0 M8 18,0
52,0 M8 21,0
57,0 M10 21,0
69,0 M10 27,0
77,0 M12 27,0
90,0 M12 27,0
108,0 M14 -
123,0 M14 -
www.gemu-group.com
T
5,5
5,5
5,5
5,0
6,5
7,5
8,5
8,5
10,0
10,0
