5.5 - Dimensions of installation of single panel with opening to the left - Top and front views
Indications for installation of subgroups, runner positions,
calculation of automation length and permitted limit measurements.
Beam length
Panel width
Useful passage or passageway width
Opening side overlap
Closure side overlap
Total automation length
Belt transmission position
Belt length
Table of measurements of single panel standard beams with opening to the left.
LTr
PL
1900
900
2100
1000
2500
1200
2900
1400
3300
1600
3700
1800
4100
2000
4300
2100
All dimensions in the following layouts are expressed in millimetres.
LTr = LA+PL+B
LA = PL+S+B
= PL
S = 40 mm
B = 30 mm
Ltot = LTr+2*25
Dtc = 170 mm
Lbelt = 2LTr-1310
LA
S
970
40
1070
40
1270
40
1470
40
1670
40
1870
40
2070
40
2170
40
OPEN
B
Ltot
30
1950
30
2150
30
2550
30
2950
30
3350
30
3750
30
4150
30
4350
EN
Lbelt
2500
2900
3700
4500
5300
6100
6900
7300
13
