5.3 - Installation dimensions for double-panel version - Top and front views
Indications for installation of subgroups, runner positions,
calculation of automation length and permitted limit measurements.
BEAM
Beam length
Panel width
Useful passage or passageway width
Overlap
Total automation length
Belt transmission position
Belt length
Minimum panel width permitted for two-panel version:
LA =500 mm
Double panel standard beam measurements table.
LTr
PL
1900
900
2100
1000
2500
1200
2900
1400
3300
1600
3700
1800
4100
2000
4300
2100
All dimensions in the following layouts are expressed in millimetres.
OPEN
LTr = 2*LA+PL
LA = (PL/2)+S
= PL
S = 50
Ltot = LTr+2*25
Dtc = LA-310
Lbelt = 2(LTr-Dtc)-740
Corresponding to a useful passage: PL =900 mm
LA
S
500
50
550
50
650
50
750
50
850
50
950
50
1050
50
1100
50
OPEN
Dtc
Ltot
190
1950
240
2150
340
2550
440
2950
540
3350
640
3750
740
4150
790
4350
EN
Lbelt
2700
3000
3600
4200
4800
5400
6000
6300
11
