3
Description
3.1 Product overview
See Figure A on the fold-out page
1
Pairing symbol
2
On/Off button
3
LED
4
Brightness sensor
5
Adjustable optics
6
Charging pins (on the underside of the Dräger FPS IMD)
7
Screw for mounting the optics
8
FPS Quick Adapter
3.2 Feature description
The In-Mask Display is inserted into a full face mask of type Dräger FPS 7000
using the FPS Quick Adapter. The optics can be set in 3 positions.
The In-Mask Display (IMD) can be paired with the following devices:
–
Dräger UCF FireCore thermal imaging camera
–
Connect ECU UI module
The In-Mask Display can be simultaneously paired with a thermal imaging
camera and a Connect ECU UI module. The information relating to the Connect
ECU UI module will then be shown in the lower left-hand corner of the thermal
image.
If the In-Mask Display is paired with a thermal imaging camera, the following
information will be shown:
–
Charge status of the rechargeable battery in the thermal imaging camera
–
Charge status of the rechargeable battery for the in-mask display
–
Square for spot temperature
–
Temperature scale
–
Numerical temperature value
Dräger FPS IMD
|
Description
en
21
