The stated vibration emission levels and stated
noise emission values were measured in ac-
cordance with a set of standardized criteria and
can be used to compare one power tool with
another.
The stated vibration emission levels and stated
noise emission values can also be used to make
an initial assessment of exposure.
Warning:
The vibration and noise emission levels may vary
from the level specifi ed during actual use, depen-
ding on the way in which the power tool is used,
especially the type of workpiece it is used for.
Limit the operating time!
All stages of the operating cycle must be conside-
red (for example, times in which the electric tools
are switched off and times in which the tool is
switched on but operates without load).
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Residual risks
Even if you use this electric power tool in
accordance with the instructions, certain
residual risks cannot be eliminated. The fol-
lowing hazards may arise in connection with
the equipment's construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is applied.
5. Before starting the equipment
The lawn mower is delivered partly assembled.
The push bar and the grass basket must be as-
sembled before using the lawn mower. Follow the
instructions step by step and refer to the pictures
when assembling.
Anl_GE_CM_18_33_Li_SPK13.indb 19 Anl_GE_CM_18_33_Li_SPK13.indb 19
GB
Important! Required assembly parts (screws,
cable guides, etc.) or functional parts (e.g. plugs,
wrenches, etc.) can be found in the molded parts
of the packaging or on the equipment.
Warning! Always pull out the safety plug be-
fore making adjustments to the equipment.
Mounting the push bar (Fig. 3 to 5)
Start by fastening the lower push bars for the
left-hand side (Fig. 3/Item 10) and the right-hand
side (Fig. 3/Item 11) to the mower housing using
the fastening screws (Fig. 3/Item 12,13a). The
upper push bar then has to be slid onto the lower
push bars and fastened with screws (Fig. 4/Item
13,13a). There are 2 diff erent holes on each of
the lower push bars for this, to enable the height
of the push bar to be adjusted to the height of the
user. Then fasten the power cable to the push bar
with the cable clips (Fig. 5/Item 14).
Mounting the catch basket (see Fig. 6)
Before you fi t the catch basket you must ensure
that the motor is switched off and the blade is not
rotating. Lift the ejector fl ap (Fig. 6/Item 6) with
one hand. With the other hand, hold the catch
basket by the handle and hook it in from above
(Fig. 6).
Filling level indicator of the grass collector
The grass box is equipped with a fi lling level in-
dicator (Fig. 1/Item 15). which is opened by the
airfl ow that the lawn mower generates during ope-
ration. If the fl ap closes during mowing, the grass
collecting device is full and must be emptied. To
ensure the proper functioning of the fi lling level
indicator, the holes under the fl ap must always be
kept clean and passable.
Adjusting the cutting height
Caution!
Adjust the cutting height only when the machine
has been switched off and the safety plug has
been pulled out.
The cutting height is adjusted as follows
(see Fig. 7):
1. Push the lever (5) downwards.
2. Set the lever (5) to the desired cutting height.
3. Release the lever (5) and check that it is se-
curely seated in the lock.
Reading off the cutting height
The cutting height can be set between 25-65 mm
in 5 intervals, and can be read off on the scale.
