NOTE!
Environmental damage!
Spilled oil can pollute the environment permanently.
The liquid is highly toxic and can quickly lead to water
pollution.
- Fill/empty oil only on level, paved surfaces.
- Use a filling nozzle or funnel.
- Collect drained oil in a suitable container.
- Wipe up spilled oil carefully immediately and dis-
pose of the cloth according to local regulations.
- Dispose of oil as per local regulations.
All protective and safety equipment must be reassem-
bled immediately after repair, maintenance is complet-
ed.
Our recommendation to you:
Clean the device thoroughly after each use using a
damp cloth and a little soft soap. Do not use any clean-
ing products or solvents; they could attack the plastic
parts of the device. Make sure that no water can pene-
trate the interior of the device.
Tool required:
• 1x open-ended spanner / socket spanner, size
24mm
• Funnel
• Drip tray
• File / angle grinder
Not included in the scope of delivery.
12.1 Splitting wedge (3) (Fig. 1)
1.
The splitting wedge (3) is a wearing part that
should be reground with a file or angle grinder or
replaced with a new splitting wedge (3) if neces-
sary.
12.2 Operating arms (4, 19) and operating levers
(5, 18) (Fig. 1)
1.
The combined retaining and control device must
remain smooth-running. Lubricate with a few
drops of oil as required.
12.3 Splitting column (2) (Fig. 1)
1.
Keep the splitting column (2) clean. Remove foul-
ing, wood chips, bark, etc.
2.
Lubricate splitting column (2) with spray oil or
grease.
48 | GB
12.4 Check the oil level regularly!
An oil level that is too low will damage the oil pump!
(See 10.2)
1.
Check the hydraulic connections and screw con-
nections for leaks regularly and retighten them if
necessary.
12.5 Topping up the hydraulic oil (Fig. 1, 12)
We recommend oil from the HLP 32 range.
Note:
The splitting column (2) must be retracted before the
check, the device must be level.
1.
Unscrew the bleed screw (15).
2.
Top up the hydraulic oil with the help of a suitable
funnel. Note the max. filling capacity of 8 l. Careful-
ly fill the oil up to the lower edge of the filling port.
3.
Wipe the oil dipstick (32) with a clean, lint-free
cloth.
4.
Screw the bleed screw (15) back into the filler neck
until it reaches the stop.
5.
Unscrew the bleed screw (15) and read the oil lev-
el in horizontal position The oil level must be be-
tween min. and max. at the dipstick (32).
6.
If the oil level is too low, repeat the process.
7.
Then screw the bleed screw (15) back in.
12.6 Changing the hydraulic oil (Fig. 1, 12)
Change hydraulic oil after 50 hours of operating time.
Every 500 hours thereafter.
Note
The hydraulic oil change should be carried out while
the motor is at operating temperature.
Note
The splitting column (2) must be retracted before the oil
change and the product must be level.
1.
Position a suitable collecting container with min.
10 litre volume.
2.
Unscrew the bleed screw (15).
3.
Remove the oil drain screw (33) with a 24mm
open-ended spanner to let the oil drain out.
4.
Screw the oil drain screw (33) back in.
5.
Fill up with new hydraulic oil (approx. 8 litres).
6.
Screw the bleed screw (15) back in.
7.
Check the oil level as described in section 10.2.
8.
Dispose of the used oil properly at a local used oil
collection point.
The time intervals cited here relate to normal operating
conditions. If the device is subjected to heavier loads,
these times must be reduced accordingly.
