Installation Requirements
Installation Environment
• Place the machine on a flat, firm, non-slippery surface, not a base
or a shelf that is unsteady or not strong enough to support the
machine.
• Do not place directly on a washing machine top cover with
insufficient fixed strength or support strength.
• If placing the washing machine on the ground, be sure to
waterproof it to avoid the risk of it getting soaked by water.
• Keep the washing machine in a well-ventilated place away from
direct sunlight and freezing weather.
• The working environment temperature should be 0°C - 40°C.
• Keep the washing machine away from heat sources such as
charcoal fires or gas stoves.
30mm
20mm
Top: ≥ 30mm
Side: ≥ 20mm
Rear: ≥ 60mm
20mm
Power Supply
• Connect the washing machine to a power supply (230V~/50Hz)
which should be correctly and reliably grounded.
• Make sure the power cord is not pinched by any objects.
Water Supply
• The washing machine requires a water pressure of 0.1MPa to
1.0MPa. Water pressure lower than 0.1MPa may cause abnormal
water inflow. In this case, the washing machine may not work
properly and will display the prompt [E1].
• Place the washing machine as close to the faucet as possible;
Check the inlet valve and all connections of the faucet for leakage.
• Do not connect the washing machine to a hot water source.
010
