Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2
Product description (Fig. 1-19)
1.
Safety bar
2.
Operating panel
2a.
ON/OFF switch (LED)
2b.
On/off switch (lawnmower)
2c.
Speed setting (travel mode)
2d.
Auto/Eco switch
2e.
Indicator LED (travel speed)
2f.
Indicator LED (lighting)
2g.
Indicator LED (slot 1)
2h.
Indicator LED (slot 2)
2i.
Charge status indicator
2j.
Indicator LED (Auto/Eco mode)
2k
Indicator LED (fault message)
3.
Drive bow
4.
Switch lock
5.
Upper push bar
5a.
M6 flat head screw
5b.
Washer
5c.
Quick clamp lever
5d.
Threaded bushing
6.
Cable clip
6a.
Cable
7.
Discharge flap
7a.
Spacer
8.
Grass collection basket
8a.
Level indicator
9.
Lower push bar
9a.
M6 flat head screw
9b.
Washer
9c.
Quick clamp lever
9d.
Threaded bushing
9e.
Push bar height adjustment
10.
Drive wheel
11.
Cutting height adjustment
12.
Water connection
13.
Idler
14.
LED
15.
Side discharge
16.
Battery cover
17.
Mulching insert
18.
Battery
18 a
Release button (battery)
19.
Battery row (slot 1)
19 a
Battery row (slot 2)
20.
Blade screw
21.
Blade
3
Scope of delivery (Fig. 2)
Item QuantityDesignation
5a.
2 x
5b.
2 x
5c.
2 x
5d.
2 x
6.
2 x
8.
1 x
9.
1 x
9a.
2 x
9b.
2 x
9c.
2 x
9d.
2 x
15.
1 x
17.
1 x
18.
2 x
1 x
1 x
* = may not be included in the scope of delivery!
4
Proper use
The product is only intended for mowing lawns and grass
in domestic situations.
This battery-powered lawnmower is suitable for a lawn ar-
ea of approx. 800 - 900 m².
The actual lawn area is influenced by factors such as the
battery charge, battery size (Ah), grass moisture, cutting
height, moss growth or grass density.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
www.scheppach.com
M6x55 mm flat head screw
Washer
Quick clamp lever
M6 threaded bushing
Cable clip
Grass collection basket
Lower push bar
M6x55 mm flat head screw
Washer
Quick clamp lever
M6 threaded bushing
Side discharge
Mulching insert
Battery*
Battery-powered lawnmower
Operating manual
GB | 23
