G E T T I N G TO K N O W YO U R H U M I D I F I E R
Function Diagram
A.
Nozzle Cap
B.
Nozzles
C.
Handle
D.
Water Tank
E.
Base
F.
Aroma Box
G.
Aroma Pad
H.
Humidity Sensor
I.
LED Display
J.
Control Panel
K.
Remote Control
Front
C
D
E
F
G H
6
L.
Mist Tube
M.
Mist Channel
N.
Absorption Pad
O.
Air Vent
P.
Inner Chamber
Q.
Power Cord
R.
Water Tank Cap
S.
Heating Element
T.
Transducer
U.
Insulation Ring
L
B
A
Back
N
O
I
J
T
U
M
Underside
of water tank
P
K
Top view of
inner chamber
S
R
D
Q
