Vetus DBPPJA Manuel D'utilisation page 9

3.2 Use
Familiarise yourself with the operation of the panel.
Do this in a safe location!
In principle, use the bow and stern thruster control panel only at low
speed or when manoeuvring the boat.
Move the joystick in the direction in which the boat is required to
move.
The thrust starts at about 25% and increases proportionally to the
maximum value as the joystick is moved further to its outermost po-
sition.
Gently move the joystick in the desired sailing direction. If necessary,
correct the direction, from the mid position, by moving the joystick
slightly up or down.
Use the rotary knob to turn the boat around its axis.
User manual DBPPJA - Proportional panel for bow and stern thruster
n
ote
3.3 Hold function
Use the HOLD function to tem-
porarily moor your boat. Do this
carefully and make sure that
your boat is not damaged, for
example by using fenders.
• Manoeuvre the boat against
the object to be moored.
• Run the bow and stern thrusters with sufficient force to press the
boat against the mooring.
• Do not move the joystick. Now press the HOLD button.
• Release the joystick.
Deactivate the HOLD function by:
- Pressing the 'HOLD' button, or
- Pressing the 'ON/OFF' button, or
- Moving the joystick in the opposite direction.
3.4 Switching OFF a panel
Keep pressing the "ON / OFF" button until all LEDs are off and you
hear the signal, di-di-di-dah-dah (... - -). The control panel is switched
off.
Automatic switching off will take place 30 minutes after the last op-
eration of the joystick.
Note: When the hold function is engaged automatic switch off
will not take place.
Here too, the buzzer will reply with the signal didididahdidah ( . . . - . - )
• Turn off the battery main switch when leaving the boat.
ENGLISH
9
020813.02
