Product Overview
A
Robot (Top View)
A1
—Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
—Power Indicator Light
• White: Battery level ≥ 15%
• Red: Battery level < 15%
• Breathing: Charging or starting up
• Flashing red quickly: Error
—Dock
• Robot not on dock: Press to start
docking / Press and hold to start
spot cleaning
• Robot on dock: Press to start
emptying / Press and hold to wash
the mop cloths
Note:
Press any button to pause a running robot.
A1-1—Reactive Tech Obstacle Avoidance
Sensor
Robot (Bottom View)
A2
A2-1—Wall Sensor
A2-2—Omnidirectional Wheel
A2-3—Carpet Sensor
A2-4—Side Brush
A2-5—Main Brush Cover
A2-6—Main Wheels
A2-7—Main Brush
A2-8—Main Brush Cover Latches
A2-9—Mop Cloths
A2-10—Cliff Sensors
Robot (Top Cover Open)
A3
A3-1—Vertical Bumper
A3-2—LiDAR Sensor
A3-3—WiFi Indicator Light
• Off: WiFi not connected
• Flashing slowly: Waiting for connection
• Flashing quickly: Connecting
• Steady: WiFi connected
A3-4—Reset Button
A3-5—Dustbin
A3-6—Charging Contacts
A3-7—Communication Sensor
A3-8—Air Outlets
A3-9—Self-Filling Port
A3-10—Automatic Lift and Rotate Mop
Modules
A3-11—Suction Inlet
A3-12—Bumper
Mop Cloth Mount
A4
A4-1—Hook and Loop Pads
A4-2—Mop Axle
Note:
Secure the mop cloths flat in place.
Mop Cloth
A5
Dustbin
A6
A6-1—Dustbin Latch
08
A6-2—Air Inlet
A6-3—Filter Latch
A6-4—Washable Filter
A6-5—Suction Inlet
Dock Base
A7
Power Cord
A8
Empty Wash Fill Dock
A9
A9-1—Water Tank Handle
A9-2—Water Tank Latch
A9-3—Dirty Water Tank
A9-4—Dust Container Cover
A9-5—Charging Contacts
A9-6—Robot Refill Port
A9-7—Suction Inlet
A9-8—Clean Water Tank
A9-9—Status Indicator Light
• Breathing: Emptying/Mop washing
• Red: Dock error
• Off: Powered off/Charging
A9-10—Drain Port
A9-11—Drying Air Outlets
A9-12—Dock Base
A9-13—Filter
A9-14—Dust Bag Slot
A9-15—Dock Location Beacon
A9-16—Clean Water Dispensers
A9-17—Water Level Float
A9-18—Cleaning Tray Filter
A9-19—Cleaning Tray
