settings. This will take about 5 minutes."
voice message. The robot will then be
restored to factory settings.
Routine Maintenance
D
Notes:
• The product must be switched off and the plug must
be removed from socket outlet before cleaning or
maintaining the product.
• The frequency of replacement may vary with the actual
situation. If abnormal wear occurs, replace the parts
immediately.
Main Brush
D1
* Clean every 2 weeks and replace every 6-12 months.
D1-1—Main Brush Cover
D1-2—Main Brush Cover Latches
D1-3—Main Brush
D1-4—Main Brush Caps
D1-5—Main Brush Bearing
D1-6—Turn over the robot and press the
two latches inwards to remove the
main brush cover.
D1-7—Pull out the main brush and remove
the main brush bearing. Rotate the
main brush caps in the direction as
shown in the diagram to remove them,
and remove any entangled hair or dirt
at both ends of the main brush and
the bearing.
D1-8—Reinstall the main brush.
D1-9—Reinstall the main brush cover. Make
sure its four teeth are fully seated in
the slots, and press the main brush
cover until you hear it lock with a click.
Notes:
• It is recommended to wipe the main brush with a wet
cloth. If the main brush is wet, air-dry it away from
direct sunlight.
• Do not use corrosive cleaning fluid or disinfectant to
clean the main brush.
Side Brush
D2
* Clean monthly and replace every 3-6 months.
D2-1—Turn over the robot, unscrew the
side brush, then remove and clean it.
D2-2—Align the central groove with the raised
position on the robot and tighten the
screw to reinstall the side brush.
Omnidirectional Wheel
D3
* Clean as required.
D3-1—Use a tool, such as a small screwdriver,
to pry out the axle slowly and take
out the wheel.
Note:
The omnidirectional wheel bracket cannot be removed.
D3-2—Rinse the wheel and the axle with
water to remove any hair and dirt.
Air-dry, reinstall, and press the wheel
and axle back in place.
Main Wheels
D4
* Clean as required.
Clean the main wheels with a soft, dry cloth.
12
Dustbin
D5
* Clean as required.
D5-1—Open the top cover of the robot and
press the dustbin latch to take out
the dustbin.
D5-2—Remove the washable filter and empty
the dustbin.
D5-3—Fill the dustbin with clean water and
reinstall the washable filter. Gently
shake the dustbin, and then pour out
the dirty water.
Note:
To prevent blockage, only use clean water without
any cleaning liquid.
D5-4—Allow at least 24 hours for the dustbin
and washable filter to dry thoroughly
before reinstalling them.
Washable Filter
D6
* Clean every 2 weeks and replace every 6-12 months.
D6-1—Remove the filter.
D6-2—Rinse the filter repeatedly and tap it
to remove as much dirt as possible.
Note:
Do not touch the surface of the filter with hands,
brushes, or sharp objects to avoid potential damage.
D6-3—Allow at least 24 hours for the filter to
dry thoroughly before reinstalling it.
Mop Cloths
D7
* Clean as required and replace every 1-3 months.
D7-1—Remove the mop cloths from the mop
cloth mounts. Clean the mop cloths and
air-dry them.
