Fault Acknowledgement; Fault Memory - Wilo Control EC-Fire Notice De Montage Et De Mise En Service

• A fault on one of the connected pumps is indi-
cated on the main screen by a flashing status sym-
bol for the relevant pump.

10.2 Fault acknowledgement

Individual errors are acknowledged using
EasyActions (see 6.2.2) or via the menu:

10.3 Fault memory

The switchgear stores the last 10 errors in the
fault memory. The memory uses the FiFo principle
(First in/First out).
Installation and operating instructions Wilo-Control EC-Fire
Select menu 6.00.
Select menu 6.01 and press the operating button --> the "off" indicator flashes.
Turn the operating button once to the right. The "Reset" indicator appears.
Press the operating button. All faults eliminated are acknowledged and the fault
LED goes out.
1. Select menu 6.00.
2. Select menu 6.02 – the last fault is displayed.
3. Turn the operating button to the right. In this
way you can scroll through the fault memory
(6.03 to 6.11).
English
59
