Protocole DMX
DMX
Value
192
Substraction effect
193
Multiplication effect
194
Minimum effect
195
Maximum effect
196-255 Reserved
Effect Speed/Time
Type of control 1
0
Presentation* (time=0.8 sec) (0=default)
1-250
Time from 0,1 sec. to 25 sec.
251-255 Stop
*Presentation serves for showing effect
Type of control 2
0
Presentation (time=0.8 sec)
1-126
Time from 0,1 sec. to 12,6 sec.
127-128 Stop
129-254 Time from 12.6 sec to 0.1 sec. - opposite direction
255
Stop
Type of control 3
0
Presentation
1-255
Effect speed from min. to max.
Type of control 4
0
Presentation (4 corners)
1-255
Number of corners from min. to max.
Type of control 5
0
Open
1-255
Iris from open to close
Type of control 6
0
Open
1-255
Mask effect from min. level to max. level
Type of control 7
0-127
Movement from edge to centre
128
Centre
129--255 Movement from centre to edge
Type of control 8
0-255
Continuous effect changing
Grey box correction
0
Open (0=default)
1 - 255
From max.diameter to min.diameter
Shutter/ strobe
0 - 15
Shutter closed, LEDs Off
16 - 31
Shutter closed, LEDs On
32 - 63
Shutter open (32=default)
Function
Page 10
Type of
control
8
8
8
8
step
proportional
step
step
proportional
step
proportional
step
step
proportional
step
proportional
step
proportional
step
proportional
proportional
step
proportional
proportional
step
proportional
step
step
step
