Mode/Total channels
1/25
2/33
19
27
20
28
21
29
Protocole DMX
DMX
Value
2-127
Reserved
128-255 Speed from original to max. (4x original speed)
Digital gobo indexing and rotation
0 - 127
Gobo indexing (0=default)
128-190 Forwards gobo rotation from fast to slow
191-192 No rotation
193- 255 Backwards gobo rotation from slow to fast
Digital gobo gobo indexing and rotation fine
0-255
Fine indexing (rotation)
Effect wheel
The following effects are controlled by means of the "Effect
speed/Time" channel below. Type of control is stated in the column
on the right.
0
Open position-hole (0=default)
ransition effects between two gobos (pictures)
T
1
Random transition
2
Transition with blending
3
Transition from left --> right, horizontally
4
Transition from right --> left, horizontally
5
Stripe transition from left --> right, horizontally
6
Stripe transition from right -->left, horizontally
7
3-stripe transition from left-->right, horizontally
8
3-stripe transition from right-->left, horizontally
9
6-stripe transition from left-->right, horizontally
10
6-stripe transition from right-->left, horizontally
11
Transition up --> down, vertically
12
Transition down -->up, vertically
13
Stripe transition up --> down, vertically
14
Stripe transition down -->up, vertically
15
3-stripe transition up-->down, vertically
16
3-stripe transition down-->up, vertically
17
6-stripe transition up-->down, vertically
18
6-stripe transition down-->up, vertically
19
Transition 2 from left --> right, horizontally (diffusion edge)
20
Transition 2 from right --> left, horizontally (diffusion edge)
21
Transition 2 up --> down, vertically (diffusion edge)
22
Transition 2 down -->up, vertically (diffusion edge)
23
Iris transition out--> in
24
Iris transition in--> out
25
Iris transition out--> in (Diffusin edge)
26
Iris transition in--> out (Diffusion edge)
27
Iris transition 3 out--> in (more diffusion edge)
28
Iris transition 3 in--> out (more diffusion edge)
29
Moving transition from left --> right
30
Moving transition from left --> right
31
Moving transition up --> down
32
Moving transition from down --> up
33
Drop transition
34
Simple transition
35
Pixel transition
Function
Page 8
Type of
control
proportional
proportional
proportional
step
proportional
proportional
step
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
