Mode/Total channels
1/25
2/33
*
14
*
15
*
16
*
17
*
18
11
19
12
20
13
21
14
22
15
23
Protocole DMX
DMX
Value
1-255
Movement of the top right corner X coordinate to center
KeyStone Top Right Y
0
Keystone Off (0=default)
1-255
Movement of the top right corner Y coordinate to center
KeyStoneBottom Right X
0
Keystone Off (0=default)
1-255
Movement of the bottom right corner X coordinate to center
KeyStone Bottom Right Y
0
Keystone Off (0=default)
1-255
Movement of the bottom right corner Y coordinate to center
KeyStone Bottom Left X
0
Keystone Off (0=default)
1-255
Movement of the bottom left corner X coordinate to center
KeyStone Bottom Left Y
0
Keystone Off (0=default)
1-255
Movement of the bottom left corner Y coordinate to center
Cyan (Red)
0 - 255
Cyan (0%-->100%) (0=default for CMY mixing mode)
0 - 255
Red (0%-->100%) (255=default for RGB mixing mode)
Magenta (Green)
0 - 255
Magenta (0%-->100%) (0=default for CMY mixing mode)
0 - 255
Green (0%-->100%) (255=default for RGB mixing mode)
Yellow (Blue)
0 - 255
Yellow (0%-->100%) (0=default for CMY mixing mode)
0 - 255
Blue (0%-->100%) (255=default for RGB mixing mode)
Virtual colour wheel
White
0-15
(CTC according to value set at channel Special Function
16
Blue
17-55
Blue ---> Cyan
56
Cyan
57-95
Cyan ---> Green
96
Green
97-134
Green ---> Yellow
135
Yellow
136-174 Yellow ---> Red
175
Red
176-214 Red ---> Magenta
215
Magenta
216-246 Magenta ---> B
247
Blue
248-255 Reserved
Colour Effect wheel
0
No function (0=default)
Static effects
1
Horizontal linear shade, white-->black
2
Horizontal Linear shade, black-->white
3
Vertical linear shade, black-->white
4
Vertical linear shade, white-->black
5
Diagonal shade, white -->black
Function
lue
Page 3
Type of
control
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
proportional
proportional
proportional
proportional
proportional
proportional
)
(0=default)
step
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
step
step
step
step
step
step
