Mode/Total channels
1/25
2/33
Protocole DMX
DMX
Value
36
Transition via blending
37
Transition with white output
38
Crossing transition
39
Picture in picture transition
40
Direct transition
41
Transition with vertical rotation
42
Transition with horizontal rotation
43
Transition with diagonal rotation
44
Transition with diagonal rotation-opposite direction
45
Zoom out transition
46
Zoom in transition
47
Zoom transition in horizontal direction
48
Zoom transition in vertical direction
49-79
Reserved
Effects applied at one gobo (picture)
80
Kaleidoscope 1
81
Kaleidoscope 2
82
Kaleidoscope 3
83
Kaleidoscope 4
84
Kaleidoscope 5
85
Sunflower Kaleidoscope (coarse)
86
Sunflower Kaleidoscope (soft)
87
Sunflower kaleidoscope (slow)
88
Sunflower kaleidoscope (faster)
89
Sunflower kaleidoscope (fastest)
90-99
Reserved
100
Circle Iris in/out
101
Circle Iris in/out (diffusion edge)
102
Vertical Ellipse Iris in/out
103
Horizontal Ellipse Iris in/out
104
Colour -> Black-and-white -> Colour
105
Colour -> Black-and-white inverted -> Colour
106
Black-and-white ->Black-and-white inverted -> Black-and-white
107
Colour -> Colour inverted -> Colour
108
Pixalation
109-179 Reserved
Manual effects
180
Circular Iris
181
Elliptical Iris -vertical
182
Elliptical Iris-horizontal
183
Black mask
184
Inverse black mask
185
White mask
186
Inverse white mask
187
Gobo/video movement in horizontal (X) axis
188
Gobo/video movement in vertical (Y) axis
189
Reserved
190
Crossfade effect
191
Addition effect
Function
Page 9
Type of
control
1
1
1
1
1
1
1
1
1
1
1
1
1
3
3
3
3
3
3
3
4
4
4
2
2
2
2
2
2
2
2
2
5
5
5
6
6
6
6
7
7
8
8
