Protocole DMX
DMX
Value
124 -129 Reserved
To activate following functions, stop in DMX value for at least 3
seconds.
130-134
Keep aspect ratio On
135-139
Keep aspect ratio Off
210 -219 Internal HDMI
220 -229 External HDMI
230 -234 Save AutoKeystoning
235 -239 Reserved
240 -244 Synchronization of the Local NAS content with NAS
The following RoboSpot related commands are only applicable when the RoboSpot
is connected:
Reserved
Digital zoom
0-127
Zoom from min. -->real size
128
Real size (128=default)
129-255 Zoom from real size -->max.
Focus
0 - 255
Continuous adjustment from far to near (128=default)
Fixture equipped with ADM: Focus has to be set at 0 DMX
Vertical keystoning
0
Vertical autoKeystoning, Corner keystones Off
1-127
Vertical keystoning correction, Corner keystones Off
128
Vertical keystoning Off, Corner keystones On (128=default)
129-255 Vertical keystoning correction - oppozite direction, Corner
keystones Off
Horizontal keystoning
0
Horizontal autoKeystoning, Corner keystones Off
1-127
Horizontal keystoning correction, Corner keystones Off
128
Horizontal keystoning Off, Corner keystones On (128=default)
129-255 Horizontal keystoning correction - oppozite direction, Corner
keystones Off
To activate the following corner Keystones below, both channels
above (Verical keystoning, Horizontal keystoning) have to be set at
128 DMX
KeyStone Top Left X
0
Keystone Off (0=default)
1-255
Movement of the top left corner X coordinate to center
KeyStone Top Left Y
0
Keystone Off (0=default)
1-255
Movement of the top left corner Y coordinate to center
KeyStone Top Right X
0
Keystone Off (0=default)
Function
Page 2
Type of
control
step
step
step
step
step
step
step
step
step
step
step
step
step
proportional
step
proportional
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
