Mode/Total channels
1/25
2/33
16
24
17
25
18
26
Protocole DMX
DMX
Value
156
Black shade -->random colour, slow rotation ,clockwise
157
Black shade -->random colour, fast rotation ,clockwise
158
Black shade -->random colour, slow rotation ,anticlockwise
159
Black shade -->random colour, fast rotation ,anticlockwise
160
Random colour in two corners, slow rotation, clockwise
161
Random colour in two corners, fast rotation, clockwise
162
Random colour in two corners, slow rotation, anticlockwise
163
Random colour in two corners, fast rotation, anticlockwise
164
Random colour in four corners, slow rotation, clockwise
165
Random colour in four corners, fast rotation, clockwise
166
Random colour in four corners, slow rotation, anticlockwise
167
Random colour in four corners, fast rotation, anticlockwise
168
Horizontal colour transition, slowly, random
169
Horizontal colour transition, fast, random
170
Vertical colour transition, slowly, random
171
Vertical colour transition, fast, random
172
Diagonal colour transition, slowly
173
Diagonal colour transition, fast
174
Horizontal/Vertical/Diagonal colour transition slowly
175
Horizontal/Vertical/Diagonal colour transition fast
176-255 Reserved
Digital gobo wheel selection
0-31
Factory Digital gobo wheel (0=default)
32-63
Internal Custom Digital gobo wheel
64-95
External Custom Digital gobo wheel (USB memory stick)
96-127
NAS content
128-159 Enable RTSP (select stream on the channel 17/25, DMX 1-20)
160-255 Reserved
Digital gobo wheel
Open (0=default)
0
If the RTSP is enabled (channel 16/24, DMX range of 128-159):
Running of Stream 1,2....19,20
1-20
If the i Factory Digital gobo wheel is activated (channel 16/24,
DMX range of 0-31), the following distribution of
gobos/pictures/animations goes for Factory Digital gobo wheel
only:
Colour pictures (by one DMX value: 1,2,3......103)
1 - 103
104-149 Black and white gobos (by one DMX value: 104, 105,......149)
150-168 Black and white animations
169-250 Colour animations (by one DMX value: 169, 170.....250)
To activate following two functions, set a transition effect (1-48
DMX) at Effect Wheel - channel 21/29
Gobos presentation (gobos selected randomly)
251
252
Gobos presentation (gobos selected in alphabetical order)
253-254 Reserved
255
White
Video speed control
0
Optimal speed (0=default)
1
Pause
Function
(by one DMX value: 150, 151,.....168)
Page 7
Type of
control
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
proportional
proportional
proportional
proportional
proportional
step
step
step
step
step
