ELECTRICAL CONNECTIONS TO TERMINALS FOR SLIDING GATE OPENING – Dip Switch B No. 1 = ON
Accessory
24V signal lamp
Output - max 3W:
24V Output:
Single-phase 230V
motor and capacitor
power supply:
230V Flashing lamp:
230V Control box
power supply:
Connections to
Pulin 3:
24Vdc - 5W Output:
page 14
XE
X
Electrical connections
Output for a 24V max 3W signal lamp
3 11
showing the state of the automation:
Signal lamp On = Gate open
Signal lamp OFF = Gate closed
0.5s (fast) flashing = closure movement
1s (normal) flashing = opening movement
24V ac OUTPUT for max load:
12 13
No. 2 pairs of photocells
No. 1 radio receiver
No. 1 Led Chis 37 / Chis E37 keyswitch
All instructions are attached to the related
control accessories
No. 1 MOTOR UP TO 0.5 HP (0.36 KW) SINGLE-PHASE 230V:
1) Connect the power supplies to one of the two outputs M1
or M2
16 17 18
16 17 18
M1
No. 1 MOTOR UP TO 1.0 HP (0.72 KW) SINGLE-PHASE 230V:
Connect the outputs from terminals 16-19, 17-21 and 18-20
in parallel.
IMPORTANT: with a 1.0 HP motor replace fuses F1 and F2
with 6.3A fuses
16 17 18 19 20 21
19 21
16 17 18 20
M1
22 23
24 25
24 25
erminal board for
3
28 27 26
28 27 26
connecting the Pulin 3
push-button panel Leds
+ -
OUTPUT
29 30
24V dc – 5W max.
29 30
UNIVERSAL ELECTRONIC CONTROL BOXES
230V 50/60Hz SINGLE-PHASE
C1
Capacitor
Motor M1
C1
Capacitor
Motor M1
Dip-Switches and LED signals of the various functions
only ELPRO XE
!
FORCE ADJUSTMENT:
Adjust the Force necessary to move the
gate by the torque selector. Beacause
of the inertia of the gate, too much force
is incorrect in accordance with EN 12445
and EN 12453 safety standards. This can
b e
OPEN/CLOSE
MOTOR RUN TIME: 0-120s
DWELL TIME
0s - 220s
DIP-SWITCH-A N°4 e N°10
ON: Pre-flashes prior to opening
OFF: no pre-flashing
4
ON: Flashing deactivated during the pause
during Automatic Operation (with Dip 3=ON)
OFF: Flashing during the pause during
10
Automatic Operation (with DIP 3=ON)
d a n g e r o u s !
