sigfox RC1 PULSE IP68 - Guide utilisateur / User guide version V4.0.0

2.2.2 Periodic transmission with history

The product allows the accumulation of several successive meter values before the periodic transmission of the set of values according to the
following scheme:
FR
EN
The parameters associated with this mode of operation are:
• Enabling and Configuring inputs (register 320)
• Historisation period (register S321)
• Sending frequency (S301)
• Anti-bounce timer period (registers S322)
Eg:
Register
S320
S301
S321
S322
Product in standby
Historical
No
period
reached?
Yes
Number of
No
recorded values
reached?
Yes
Send frame
0x5A and/or 0x5B
Value encoding
Hexadecimal
Decimal
Decimal
Hexadecimal
Detected
and validated
pulse?
Yes
Counting
of the impulse
Sending according to channel activation:
• 5A frame for channel A
• 5B frame for channel B
Value Result
0x39 Channel A :
• Activated
• Meter other than gas
• Tamper input activated
Channel B :
• Activated
• Gas meter
• Tamper input disabled
4 Sending every 4 historisations (saving)
300 Historisation of the data every 10 minutes (300x2 sec-
onds=600 seconds).
0x57 Anti-rebound :
• Channel A = 500ms
• Channel B = 100ms
No
