The noise level of this machine may exceed 85
dB(A). In this case, noise protection is necessary for
the user. The machineʼs noise was measured in
accordance with prEN ISO 10518. The level of
vibrations at the handle is < 2,5 m/s
were taken in accordance with prEN ISO 10518.
5. Installation
5.1 Installing the safety hood (Fig. 4-7)
Secure the edge guide to the safety hood (Fig. 4-
5) using the two securing screws (Fig. 2/Item 13).
Place the safety hood on the trimmer (Fig. 6) and
secure to the trimmer (Fig. 7) it using the four
securing screws (Fig. 2 / Item 12).
5.2 Installing the additional handle (Fig. 8 – 9)
Undo the securing screw from the handle and
then place the handle on the main handle (Fig. 8)
and secure it with the screw (Fig. 9).
6. Proper use
The trimmer is designed for cutting lawns and small
areas of grass in private and hobby gardens. Tools
for private and hobby gardens are not suitable for
use in public facilities, parks and sport centers, along
roadways, on farms or in the forestry sector. For the
tool to be used properly it is imperative to follow the
instructions set out in the manufacturerʼs directions
for use. Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
Important! It is prohibited to use the tool to chop
material for composting because of the potential
danger to persons and property.
7. Before starting the machine
The height adjustment and adjustment of the
additional handle allow you to set the machine to a
perfect working position for you.
Height adjustment (Fig. 13)
Undo the union nut (Fig. 13/Item 5) until the grass
trimmer handle can be moved in and out freely. Now
set the required working height and secure the handle
in this position by tightening the union nut again.
Adjusting the additional handle (Fig. 9)
Undo the securing screw on the additional handle
until it can be moved forwards and backwards without
any great resistance. Set the required position and
18.01.2007 11:18 Uhr Seite 15
All manuals and user guides at all-guides.com
tighten the securing screw again.
Adjusting the angle of the guide handle (Fig. 14)
Place the grass trimmer on a firm surface. Press the
2 . Measurements pedal for adjusting the angle from above using your
foot (Fig. 14/Item 9). You can now set the handle to
the required angle. Release the pedal and allow the
handle to lock into position to fix the angle. Three
different locking angles are possible.
8. Starting up
The grass trimmer is designed only to cut grass.
A short or worn down nylon line leads to poor cutting
quality.
IMPORTANT! Make sure that you unplug the
rechargeable battery before adjusting the line
length (Fig. 15-16)!
The grass trimmer has a semi-automatic line
extension system. Each time you activate the semi-
automatic line extension system, the line will be
extended to ensure that you can cut your lawn with
the perfect cutting width at all times.
Please note that the wear on the line will be
increased if you activate the semi-automatic line
extension system frequently.
Note
If the line is too long when you use the machine
for the first time, the surplus end of it will be cut
by the blade on the safety hood.
If the line is too short when you start the machine
for the first time, press the knob on the line spool
and pull the line hard. When you then start the
machine for the first time the line will be cut to
the perfect length automatically.
Remove the knife guard. Caution: Risk of injury!
Now insert the rechargeable battery (Fig. 16). The
line will be cut to the correct length when the cutting
head starts up again. A short or worn nylon line
produces poor cutting results.
Your grass trimmer will work at its best if you
observe the following instructions:
Never use the grass trimmer without its safety
devices.
Do not cut grass when it is wet. The best results
are had on dry grass.
To switch on your grass trimmer, press the safety
lock-off and the ON/OFF switch (Fig.1/Pos. 2).
To switch off your grass trimmer, let go of the
