SURFACE OPERATION

Oven Light
WARNING
Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
Allow oven to cool completely, then remove oven racks and
rack guides. To remove the light cover, gently pry bottom
edge with a flat screwdriver. Remove existing bulb and
replace with a 20-watt halogen bulb. Refer to the illustration
below.
LIGHT
COVER
Light bulb replacement.
|
10 English
Surface Burners
To light a burner, push and turn the corresponding control
knob counterclockwise to . The igniter will begin to click
until burner is lit. Once lit, continue to turn knob counter-
clockwise to desired setting.
To select a simmer setting, turn control knob to the detent
at the lowest setting. Push and continue to turn counter-
clockwise. The flame will transition to the second tier on
the burner cap. Continue to turn knob to desired simmer
setting.
CAUTION
Never leave pans on a high setting unattended. Be
careful when cooking food in fat or grease; it can
become hot enough to ignite.
Infrared Chargrill
The chargrill has an infrared burner that transfers intense
heat to food, searing the outside to seal in juices. Cook food
directly on the chargrill grate, do not use cookware. The
back 178 mm of the chargrill is cooler than the rest of the
surface. This area can be utilized to hold foods until they are
ready to serve.
Assemble chargrill:
To assemble, position chargrill frame on the range. Refer
1
to the illustration below.
Align slots of the radiant plate with front angle of frame.
2
Refer to the illustration below. Slots should fit over front
angle and sit flat on chargrill frame.
Install chargrill grate.
3
CAUTION
Use care when assembling chargrill to avoid contact
with igniter.
FRAME
IGNITER
FRONT SLOT
ANGLE
Chargrill frame. Chargrill radiant plate.
CHARGRILL OPERATION
Stainless steel cover must be removed prior to operation.
Turn on ventilation.
1
Push and turn control knob counterclockwise to
2
Igniter will begin to click until burner is lit.
Allow to preheat for 10 minutes.
3
CHARGRILL CARE
• After cooking is complete, allow chargrill to remain on
for 10 minutes. High heat will help burn off excess food
particles.
• When cool, remove grate and place in sink. Cover with
wet dish towels and pour hot water over it to help loosen
residue. Clean with soap and a scouring pad. Rinse and
dry.
• To clean the frame, remove and place in sink. Soak in hot
water and mild detergent. Wash thoroughly and scrub
with scouring pad.
RADIANT
PLATE
.
