INSTALLATION AND CONFIGURATION
4.6 Connection of the Handpieces to the Device
1
Channel 1 (CH1) allows the connection of
the PIEZOSURGERY medical handpiece
®
that can be equipped with the sterile,
single-use PIEZOSURGERY medical
®
inserts.
Channel 2 (CH2) allows the connection of
CH 2
the PIEZOSURGERY medical+ handpiece
®
that can be equipped with the sterile,
CH 1
single-use PIEZOSURGERY medical+
®
inserts.
Insert the handpiece connector into
the suitable port located on the front
panel of the device, assuring that the
index point on the connector is aligned
with the index point on the ring nut of
the connector port. Gently push the
handpiece connector until it is completely
inserted;
CAUTION: To avoid damaging
the cord-handpiece, connect and/or
disconnect it, holding it by the connector
only. Never pull the cord.
