Switching on and off, Fig. 1 / Pos. 1
Press the green button for switching on.
Press the red button for switching off.
Note: Check the function of the ON/OFF unit before
every use by switching on and off once.
Check turning direction of motor see chapter 13. Elec-
trical connection / Phase inverter.
Restarting safety in case of current interruption
(no-volt release).
In case of current failure, inadvertent pulling of the
plug, or a defective fuse, the machine is switched off
automatically. For switching on again, press anew the
green button of the switch unit.
End of work
• Move the splitting knife to the lower position.
• Release one operating arm.
• Switch the machine off and pull the power plug.
• Close the venting cap.
• Observe the general maintenance instructions.

9. Working instructions

Stroke limit for short logs, Fig. 9
Lower splitting knife position about 10 cm above table.
• Move splitting knife to the desired position
• Release one operating arm
• Switch motor off
• Release the second operating arm
• Release the locking screw (5)
• Push the stroke set rod (N) to the top until it is
stopped by the spring
• Retighten the locking screw (5)
• Switch motor on
• Check upper position
Functional test
Test the function before every use.
Action:
Push both handles Splitting knife goes down
towards below. to approx. 10 cm above the
table.
Let one handle Splitting knife stops in the
loose, then the other. desired position.
Let both handles Splitting knife returns to up-
loose. per position.
Check the oil level before every use – see chapter
"Maintenance".
Splitting
• Place the log on the table, hold it with both handles,
press the handles down. As soon as the splitting
knife enters the wood, push the handles down and
to the outside at the same time. This prevents the
wood from putting pressure on the operating arms.
• Only split straight cut logs.
• Split the logs in vertical position.
All manuals and user guides at all-guides.com
Result:
• Never split in horizontal position or across.
• Wear protective gloves when splitting.
Attention: When operating the machine the pivoting
table must always be in the locked position!
Pivoting table for short pieces of wood up to 60
cm, Fig. 8.1
In order to split wood, both of the pivoting tables must
be in the operating position and locked.
Pivoting table for wood up to 96,5 cm, Fig. 8.2
In order to split wood of this length, the lower pivoting
table must be in the operating position and locked.
Table for long pieces of wood up to 104/133 cm,
Fig. 8.3
In order to split wood of this length, both pivoting ta-
bles must be swung outward.
Rational working method
- Upper position approx. 5 cm above log.
- Lower position approx. 10 cm above table.
ACCIDENT PREVENTION STANDARDS
1) The machine may only be operated by people who
are well familiar with the contents of this manual.
Before use, check the intactness and perfect
2)
function of the safety devices.
Before use, make yourself also familiar with the
3)
control mechanisms of the machine, following the
operating instructions.
4) The capacity of the machine indicated may not be
surpassed. In no way may the machine be used
for any other purposes than splitting firewood.
In agreement with your country's laws, the per-
5)
sonnel must wear adequate, close-fitting working
clothes. Jewelry like watches, rings and necklac-
es must be taken off. Long hair must be protected
by a hair net.
The work place should always be tidy and clean.
6)
Tools, accessories and wrenches should lie with-
in reach.
During cleaning or maintenance work, the ma-
7)
chine may never be connected to the mains.
8) It is strictly prohibited to use the machine with
the safety devices removed or switched off.
It is strictly prohibited to remove or modify the
9)
safety devices.
Before undertaking any maintenance or adjusting
10)
work, carefully read and understand the present
operating instructions.
11) For a good performance of the machine as well
as for safety reasons, the plan given herein must
be adhered to.
In order to prevent accidents, the safety labels
12)
must always be kept clean and legible, and they
must be strictly observed. Any missing labels
must be reordered from the manufacturer and be
attached to the correct place.
