Exploded Diagram - Techness RUN 100 Manuel De L'utilisateur

Factory
Item
code
N01
N02 041800001
N03 052500002
N04 040800003
N05 020100004
N06 021000001
N07 022000002
N08 040300017
N09 039040011
N10 020900002
N11 080000006
N12 020800001
N13
N14
N15 020800002
N16 020500017
N17 020200004
N18 040200001
N19 040200002
N20 031300021
N21 0530000012
N22 052000001
N23 040800008
N24 020200003
N25 040800004
N26 032800002
N27 049900058
N28 026200001
N29
N30 020100002
N31
N32 053000007
N33 020000013
N34 020300001
N35 020300002
N36 030000003
N37 051000001
N38 036000004
N39
N40 036500002
N41
N42 031100041
N43 033700001

EXPLODED DIAGRAM

Description
bottom steel bracket
Φ60 moving wheel
adjustable cushion
end cap
cup head hex screw
flat washer- Class C
1 non-metal hex nut
console lower cover
safety key
hex screw
running deck
cross pan screw
filter fixed plate
main steel bracket
cross screw
cross pan screw
hex screw
left end cap
right end cap
button board
running deck rubber plate
rubber cushion
30*20 end cap
hex screw
40*25 end cap
speed sensor
position plate
gas spring
tube
cup head hex screw
motor support bracket
motor cushion plate
hex blot
hex bolt
hex bolt
motor
v-belt
filter
transformer plate
reactor
tube
lower controller
on/off switch
18
Specification
steel
Φ60*25
Φ44.2*35
for 20*20*T1.5 tube
M8*45 tooth: 20
Φ8
M8
715*350*27.5
M10*28
1125*556*T15
ST4.2*13
steel
ST4.2*13
M6*25
M8*80 full tooth
111.5*106*77.5
111.5*106*77.5
8PIN, 150mm
45*33*T3.0
Φ30*20
for 30*20*1.5 tube
M8*55 full tooth
for 40*25 tube
900mm 2PIN
φ18*φ8.5*T3.2
10KG, 644mm
20*20*1.5*361mm
M8*35 full tooth
steel
100*92.5*T1.5
M8*30
M8*12 full tooth
M8*35, tooth: 15
1.75HP, 180V
180J
6vv1(7251-4)
T5817-1 ACL-2.5mH-6A
steel
AC220V, B306V03
250V AC/8A
Qty.
1
2
4
1
8
31
12
1
1
2
1
2
1
1
13
2
2
1
1
1
4
2
2
1
2
1
2
1
1
1
1
1
2
4
2
1
1
1
1
1
1
1
1
