Pos. Name Explanation
Operating Navigate menus and edit content by turn-
3.4
button ing and pressing.
Back button Menu navigation:
• To go back to the previous menu level
(briefly press once).
• To go back to the previous setting (briefly
3.5 press once).
•To go back to the main menu (press once
and hold for > 1 s).
Turns key lock on or off in combination
with the context button > 5 s.
Context but- Opens the context menu with additional
ton options and functions.
3.6
Turns key lock on or off in combination
with the back button > 5 s.
LED display Indicates error code and Bluetooth PIN.
5.1
LED display Triggers the pump venting function when
5.2 operating pressed. Turning is not possible.
button
Table 7: Description of operating elements
Settings on pump
Carry out settings by turning and pressing the operating button.
Turn : Menu selection and parameter setting.
Installation and operating instructions Wilo-Stratos MAXO/-D/-Z
All manuals and user guides at all-guides.com
▪ Stratos MAXO/Stratos MAXO-D: The pump runs in the factory set-
▪ Stratos MAXO-Z: The pump runs in the factory setting ➜ Applica-
Press : Activation of the menus or confirming selected
parameters.
Initial settings menu
The settings menu will appear in the display during initial commis-
sioning of the pump.
ting ➜ Application: Radiator; Control mode: Dynamic Adapt plus.
tion: Domestic hot water circulation; control mode: Temperature T-
const.
WELCOME - WILO-STRATOS MAXO
Start with factory settings
Pump operates for radiator
Start venting
Automatic procedure
First settings
for commissioning
Fig. 1: Initial settings menu
If necessary, press the Context button
menu to change the language.
The pump runs in factory setting when the initial commissioning
menu is open.
en
The pump has been
successfully installed!
Pump is currently running
in factory setting:
Application:
Radiator
Control mode:
Dynamic Adapt plus
and go to the Language
