fr 44 | EV 3000 | Dépannage
Status
Code Description
042204 System L2 input UVP
042205 System L3 input UVP
042206 PSU L1 input OVP
042207 PSU L2 input OVP
042208 PSU L3 input OVP
042209 PSU L1 input UVP
042210 PSU L2 input UVP
042211 PSU L3 input UVP
042212 System L1 input drop
042213 System L2 input drop
042214 System L3 input drop
042223 System ambient/inlet OTP
042224 System critical point OTP
042225 PSU ambient/inlet OTP
042226 PSU critical point OTP
042227 Aux. power module OTP
042228 Relay board/smart box OTP
042232 AC connector OTP
042233 RCD/CCID trip
042237 SPD trip
042238 Main power breaker trip
042239 Aux. power breaker trip
042240 PSU communication fail
042241 WiFi module communication fail
042242 3G/4G module communication fail
042244 Bluetooth module communication fail
042246 Aux. power module communication fail
042247 Relay control boaed/smart box communi-
cation fail
042251 Emergency stop
042252 Door open
042253 System fan decay
042254 Fail to create share memory
042255 CSU initialization failed
042257 MCU self-test Fault
042258 Relay self-test Fault
042262 System AC L1 output Circuit Short
042263 PSU Duplicate ID
042264 PSU Output Short Circuit
042265 PSU Discharge Abnormal
042266 PSU Dc Side ShutDown
042267 PSU Failure Alarm
042268 PSU Protection Alarm
042269 PSU FanFailure Alarm
042270 PSU Input UVP
042271 PSU Input OVP
042272 PSU WalkIn State
042273 PSU Power Limited State
|
SP0 150 2139 VER.00
Status
Code Description
042274 PSU Id Repeat
042275 PSU Severe Uneven Current
042276 PSU Three Phase Input Inadequate
042277 PSU Three Phase Onput Imbalance
042278 PSU Ffc Side ShutDown
042279 NO PSU Resource
042280 Self test Failed due to communication of
Relayboard failure
042281 Self test Failed due to communication of
Fanboard failure
042282 Self test Failed due to communication of
Primary failure
042283 Self test Failed due to communication of
Chademoboard failure
042284 Self test Failed due to communication of
CCSboard failure
042285 Self test Failed due to AC Contact failure
042286 Self test Failed due to communication of
PSU failure
042287 Self test Failed due to Model name is none
match
042291 Self test Failed due to communication of
GBTboard failure
042292 Self test Failed due to communication of
AC failure
042293 Self test Failed due to communication of
Ledboard failure
042294 AC input ovp
042295 AC input uvp
042299 System AC L2 output OCP
042300 System AC L3 output OCP
042301 System AC L2 output Circuit Short
042302 System AC L3 output Circuit Short
042305 Meter communication timeout
042306 The dip switch of the PSU may be incorrect
042307 Psu Fuse Burn-Out
042308 Psu Pfc And Dcdc Communication Fault
042309 Psu Bus Voltage Unbalance
042310 Psu Bus Over Voltage
042311 Psu Bus Voltage Abnormal
042312 Psu Bus Under Voltage
042313 Psu Input Phase Loss
042314 Psu Fan Full Speed
042315 Psu Temperature Power Limit
042316 Psu Ac Power Limit
042317 Psu Dcdc Eeprom Fault
042318 Psu Pfc Eeprom Fault
042319 Psu Dcdc Over Voltage
043600 Normal stop charging by user
043601 Charging Time's up
043602 Replace system air filter
