Status
Code Description
012253 System fan decay
012254 Fail to create share memory
012255 CSU initialization failed
012256 AC Ground Fault
012257 MCU self-test Fault
012258 Relay self-test Fault
012259 CHAdeMO ground fault detection time-
out (GFD)
012260 CCS ground fault detection timeout (GFD)
012261 GB/T ground fault detection timeout (GFD)
012262 System AC L1 output Circuit Short
012263 PSU Duplicate ID
012264 PSU Output Short Circuit
012265 PSU Discharge Abnormal
012266 PSU Dc Side Shutdown
012267 PSU Failure Alarm
012268 PSU Protection Alarm
012269 PSU Fan Failure Alarm
012270 PSU Input UVP
012271 PSU Input OVP
012272 PSU WalkIn State
012273 PSU Power Limited State
012274 PSU Id Repeat
012275 PSU Severe Uneven Current
012276 PSU Three Phase Input Inadequate
012277 PSU Three Phase Input Imbalance
012278 PSU Pfc Side Shutdown
012279 Reserved
012280 Self-test Failed due to communication of
Relay board failure
012281 Self-test Failed due to communication of
Fan board failure
012282 Self-test Failed due to communication of
Primary(STM of DCM) failure
012283 Self-test Failed due to communication of
CHAdeMO board failure
012284 Self-test Failed due to communication of
CCS board failure
012285 Self-test Failed due to AC Contact failure
012286 Self-test Failed due to communication of
PSU failure
012287 Self-test Failed due to Model name is none
match
012288 CCS output UVP
012289 CHAdeMO output UVP
012290 GBT output UVP
012291 Self-test Failed due to communication of
GBT board failure
012292 Self-test Failed due to communication of
AC failure
012293 Self-test Failed due to communication of
LED board failure
© Bosch Automotive Service Solutions Inc.
Troubleshooting | EV 3000 | 15
Status
Code Description
012294 AC input OVP
012295 AC input UVP
012296 CHAdeMO ground fault detection - warning
012297 CCS ground fault detection - warning
012298 GBT ground fault detection - warning
012299 System AC L2 output OCP
012300 System AC L3 output OCP
012301 System AC L2 output Circuit Short
012302 System AC L3 output Circuit Short
012303 CCS liquid chiller water level warning
012304 Disconnected from power cabinet
012305 Meter communication timeout
012306 The dip switch of the PSU may be incorrect
012307 Psu Fuse Burn-Out
012308 Psu Pfc And Dcdc Communication Fault
012309 Psu Bus Voltage Unbalance
012310 Psu Bus Over Voltage
012311 Psu Bus Voltage Abnormal
012312 Psu Bus Under Voltage
012313 Psu Input Phase Loss
012314 Psu Fan Full Speed
012315 Psu Temperature Power Limit
012316 Psu Ac Power Limit
012317 Psu Dcdc Eeprom Fault
012319 Psu Dcdc Over Voltage
012320 Reserved
012321 Reserved
012322 Reserved
012323 Reserved
012324 Reserved
012325 Reserved
012326 Reserved
012327 Reserved
013600 Normal stop charging by user
013601 Charging Time's up
013602 Replace system air filter
013603 Reach to CHAdeMO max. plugging times.
013604 Reach to CCS max. plugging times.
013605 Reach to GBT max. plugging times.
013606 Reach to AC max. plugging times.
013607 CSU firmware update fail
013608 CHAdeMO Module firmware update fail
013609 CCS Module firmware update fail
013610 GB Module firmware update fail
013611 Aux. power module firmware update fail
013612 Relay control module firmware update fail
013613 LCM module firmware update fail
013614 Bluetooth module firmware update fail
|
