14 | EV 3000 | Troubleshooting
12.1
Status Codes
Status
Code
Description
011001
CHAdeMO output fuse blew
011002
CCS output fuse blew
011003
GB output fuse blew
011004
RCD/CCID self-test fail
011005
AC input contractor 1 welding
011006
AC input contractor 1 driving fault
011007
AC input contractor 2 welding
011008
AC input contractor 2 driving fault
011009
AC output relay welding
011010
AC output relay welding
011011
CHAdeMO output relay welding
011012
CHAdeMO output relay driving fault
011013
CCS output relay welding
011014
CCS output relay driving fault
011015
GB output relay welding
011016
GB output relay driving fault
011017
AC connector temperature sensor broken
011018
CHAdeMO connector temperature sensor
broken
011019
CCS connector temperature sensor broken
011020
GB connector temperature sensor broken
011021
Wi-Fi module broken
011022
3G/4G module broken
011023
Aux. power module broken
011024
Relay control module /smart box broken
011025
CHAdeMO connector lock fail
011026
GB connector lock fail
011027
AC connector lock fail
011028
CHAdeMO module broken
011029
CCS module broken
011030
GBT module broken
011031
PSU module broken
011032
RCD/CCID module broken
011033
Maximum Output Current setup error
011034
Shutter fault
011035
BLE module broken
011036
Rotary switch fault
011037
Reserved
011038
Reserved
011039
Reserved
011040
Reserved
012200
System L1 input OVP
012201
System L2 input OVP
012202
System L3 input OVP
012203
System L1 input UVP
012204
System L2 input UVP
012205
System L3 input UVP
|
SP0 150 2139
VER.00
.
Status
Code
Description
012206
PSU L1 input OVP
012207
PSU L2 input OVP
012208
PSU L3 input OVP
012209
PSU L1 input UVP
012210
PSU L2 input UVP
012211
PSU L3 input UVP
012212
System L1 input drop
012213
System L2 input drop
012214
System L3 input drop
012215
System AC output OVP
012216
System AC L1 output OCP
012217
System CHAdeMO output OVP
012218
System CHAdeMO output OCP
012219
System CCS output OVP
012220
System CCS output OCP
012221
System GB output OVP
012222
System GB output OCP
012223
System ambient/inlet OTP
012224
System critical point OTP
012225
PSU ambient/inlet OTP
012226
PSU critical point OTP
012227
Aux. power module OTP
012228
Relay board/smart box OTP
012229
CHAdeMO connector OTP
012230
CCS connector OTP
012231
GB connector OTP
012232
AC connector OTP
012233
RCD/CCID trip
012234
CHAdeMO GFD trip
012235
CCS GFD trip
012236
GB GFD trip
012237
SPD trip
012238
Main power breaker trip
012239
Aux. power breaker trip
012240
PSU communication fail
012241
Wi-Fi module communication fail
012242
3G/4G module communication fail
012243
RFID module communication fail
012244
Bluetooth module communication fail
012245
LCM module communication fail
012246
Aux. power module communication fail
012247
Relay control board/smart box communi-
cation fail
012248
CCS module communication fail
012249
CHAdeMO module communication fail
012250
GBT module communication fail
012251
Emergency stop
012252
Door open
© Bosch Automotive Service Solutions Inc.
