Status
Code Description
042273 PSU Power Limited State
042274 PSU Id Repeat
042275 PSU Severe Uneven Current
042276 PSU Three Phase Input Inadequate
042277 PSU Three Phase Onput Imbalance
042278 PSU Ffc Side ShutDown
042279 NO PSU Resource
042280 Self test Failed due to communication of
Relayboard failure
042281 Self test Failed due to communication of
Fanboard failure
042282 Self test Failed due to communication of
Primary failure
042283 Self test Failed due to communication of
Chademoboard failure
042284 Self test Failed due to communication of
CCSboard failure
042285 Self test Failed due to AC Contact failure
042286 Self test Failed due to communication of
PSU failure
042287 Self test Failed due to Model name is none
match
042291 Self test Failed due to communication of
GBTboard failure
042292 Self test Failed due to communication of
AC failure
042293 Self test Failed due to communication of
Ledboard failure
042294 AC input ovp
042295 AC input uvp
042299 System AC L2 output OCP
042300 System AC L3 output OCP
042301 System AC L2 output Circuit Short
042302 System AC L3 output Circuit Short
042305 Meter communication timeout
042306 The dip switch of the PSU may be incorrect
042307 Psu Fuse Burn-Out
042308 Psu Pfc And Dcdc Communication Fault
042309 Psu Bus Voltage Unbalance
042310 Psu Bus Over Voltage
042311 Psu Bus Voltage Abnormal
042312 Psu Bus Under Voltage
042313 Psu Input Phase Loss
042314 Psu Fan Full Speed
042315 Psu Temperature Power Limit
042316 Psu Ac Power Limit
042317 Psu Dcdc Eeprom Fault
042318 Psu Pfc Eeprom Fault
042319 Psu Dcdc Over Voltage
043600 Normal stop charging by user
043601 Charging Time's up
043602 Replace system air filter
© Bosch Automotive Service Solutions Inc.
Troubleshooting | EV 3000 | 21
Status
Code Description
043607 CSU fimrware update fail
043611 Aux. power module fimrware update fail
043612 Relay control module fimrware update fail
043614 Bluetooth module fimrware update fail
043615 WiFi module fimrware update fail
043616 3G/4G module fimrware update fail
043617 SMR fimrware update fail
043618 RFID module fimrware update fail
043619 configured by USB flash drive
043620 configured by backend
043621 configured by webage
043622 disconnected from Internet through Eth-
ernet
043623 disconnected from Internet through WiFi
043624 disconnected from Internet through 3G/4G
043625 disconnected from AP through WiFi
043626 disconnected from APN through 3G/4G
043627 WiFi disabled (separated charger only)
043628 4G disabled (separated charger only)
|
